Disjoncteur modulaire 40A PLG 4/6 Xpole (264699)

SPÉCIFICATIONS GÉNÉRALES
PRODUCT NAME
Eaton Moeller series xPole - PLG4/6 MCB
CATALOG NUMBER
264699
EAN
4015082646998
PRODUCT LENGTH/DEPTH
86 mm
PRODUCT HEIGHT
73 mm
PRODUCT WIDTH
17.5 mm
PRODUCT WEIGHT
.13 kg
COMPLIANCES
RoHS conform
MODEL CODE
PLG6-C40/1N
DELIVERY PROGRAM
APPLICATION
Switchgear for residential and commercial applications
xPole - Switchgear for residential and commercial applications
NUMBER OF POLES
Single-pole + N
NUMBER OF POLES (TOTAL)
2
NUMBER OF POLES (PROTECTED)
1
TRIPPING CHARACTERISTIC
C
RELEASE CHARACTERISTIC
C
AMPERAGE RATING
40 A
TYPE
Miniature circuit breaker
PLG6
TECHNICAL DATA - ELECTRICAL
VOLTAGE TYPE
AC
RATED OPERATIONAL VOLTAGE (UE) - MAX
230 V
RATED INSULATION VOLTAGE (UI)
440 V
RATED IMPULSE WITHSTAND VOLTAGE (UIMP)
4 kV
FREQUENCY RATING - MIN
50 Hz
FREQUENCY RATING - MAX
60 Hz
RATED SWITCHING CAPACITY (IEC/EN 60898-1)
6 kA
RATED SHORT-CIRCUIT BREAKING CAPACITY (EN 60898) AT 230 V
6 kA
RATED SHORT-CIRCUIT BREAKING CAPACITY (EN 60898) AT 400 V
6 kA
RATED SHORT-CIRCUIT BREAKING CAPACITY (IEC 60947-2) AT 230 V
10 kA
RATED SHORT-CIRCUIT BREAKING CAPACITY (IEC 60947-2) AT 400 V
10 kA
OVERVOLTAGE CATEGORY
III
POLLUTION DEGREE
2
TECHNICAL DATA - MECHANICAL
WIDTH IN NUMBER OF MODULAR SPACINGS
1
BUILT-IN DEPTH
70.5 mm
DEGREE OF PROTECTION
IP20
CONNECTABLE CONDUCTOR CROSS SECTION (SOLID-CORE) - MIN
1 mm²
CONNECTABLE CONDUCTOR CROSS SECTION (SOLID-CORE) - MAX
25 mm²
CONNECTABLE CONDUCTOR CROSS SECTION (MULTI-WIRED) - MIN
1 mm²
CONNECTABLE CONDUCTOR CROSS SECTION (MULTI-WIRED) - MAX
25 mm²
DESIGN VERIFICATION AS PER IEC/EN 61439 - TECHNICAL DATA
RATED OPERATIONAL CURRENT FOR SPECIFIED HEAT DISSIPATION (IN)
40 A
HEAT DISSIPATION PER POLE, CURRENT-DEPENDENT
0 W
EQUIPMENT HEAT DISSIPATION, CURRENT-DEPENDENT
7.4 W
STATIC HEAT DISSIPATION, NON-CURRENT-DEPENDENT
0 W
HEAT DISSIPATION CAPACITY
0 W
AMBIENT OPERATING TEMPERATURE - MIN
-25 °C
AMBIENT OPERATING TEMPERATURE - MAX
75 °C
